Current load

≤ 10 A

Integrated fine-wire fuse

–

Power LED

green

Defect LED

–

Diagnostics

–

Current consumption K-bus

–

Nominal voltage

24 V DC

Electrical isolation

yes

Reported to K-bus

–

Shield connection

–

Renewed infeed

yes

Connection facility to additional power contact

1

K-bus, looped through

yes

Bit width in the process image

0

Electrical connection to DIN rail

–

Housing width

12 mm

Weight

approx. 50 g

Side by side mounting on Bus Terminals with power contact

yes

Side by side mounting on Bus Terminals without power contact

yes

Operating temperature

-25…+60°C

Storage temperature

-40…+85°C

Plug-in wiring level

for all KSxxxx Bus Terminals

Approvals/markings

CE, CCC, UL, ATEX, IECEx, DNV

Ex marking

ATEX:
II 3 G Ex ec IIC T4 Gc
IECEx:
Ex ec IIC T4 Gc
