Number of inputs

2

Power supply

via the K-bus

Signal voltage

0…10 V

Technology

single-ended

Internal resistance

typ. > 200 kΩ

Common mode voltage UCM

–

Conversion time

~ 2 ms

Resolution

12 bit

Measurement error/uncertainty

< ±0.3% (relative to full scale value)

Electrical isolation

500 V (K-bus/signal voltage)

Current consumption power contacts

– (no power contacts)

Current consumption K-bus

typ. 60 mA

Bit width in the process image

input: 2 x 16 bit data (2 x 8 bit control/status optional)

Configuration

no address or configuration setting

Weight

approx. 60 g

Operating temperature

0…55°C

Storage temperature

-25…+85°C

Relative humidity

95%, no condensation

Vibration/shock resistance

conforms to EN 60068-2-6/EN 60068-2-27

EMC immunity/emission

conforms to EN 61000-6-2/EN 61000-6-4

Protect. rating/installation pos.

IP20/variable

Approvals/markings

CE, CCC, UL, ATEX, IECEx

Plug-in wiring level

for all KSxxxx Bus Terminals

Ex marking

ATEX:
II 3 G Ex ec IIC T4 Gc
IECEx:
Ex ec IIC T4 Gc
