Number of inputs

4 (single-ended)

Power supply

via the E-bus

Signal voltage

-10…+10 V

Distributed clocks

–

Internal resistance

> 130 kΩ

Input filter limit frequency

1 kHz

Dielectric strength

max. 30 V

Conversion time

0.625 ms default setting, configurable, multiplex

Resolution

12 bit (16 bit presentation incl. sign)

Measurement error/uncertainty

< ±0.3% (relative to full scale value)

Electrical isolation

500 V (E-bus/signal voltage)

Current consumption E-bus

typ. 130 mA

Current consumption power contacts

–

Bit width in the process image

inputs: 16 byte

Configuration

no address or configuration setting required

Special features

standard and compact process image, switchable measuring data representation, activatable FIR/IIR filters, limit value monitoring, overload display in the process data

Weight

approx. 70 g

Operating temperature

-25…+60°C

Storage temperature

-40…+85°C

Relative humidity

95%, no condensation

Vibration/shock resistance

conforms to EN 60068-2-6/EN 60068-2-27

EMC immunity/emission

conforms to EN 61000-6-2/EN 61000-6-4

Plug-in wiring level

for all ESxxxx terminals

Protect. rating/installation pos.

IP20/variable

Approvals/markings

CE, CCC, UL, ATEX, IECEx

Ex marking

ATEX:
II 3 G Ex ec IIC T4 Gc
IECEx:
Ex ec IIC T4 Gc
